One of the nickel, chromium, and molybdenum alloys known as alloy C276 is a version of hastelloy. It also has a number of additions. This alloy gains strength from the tungsten additive. This alloy exhibits strong resistance to corrosion. The alloy has a very strong resistance to pitting corrosion because of its nickel and molybdenum concentrations. The Hastelloy C276 UNS N10276 is resistant to oxidising agents because of its chromium concentration. Because the composition contains extremely little carbon, there is very little carbide precipitation in the alloy during welding. Among the Hastelloy range, DIN 2.4819 has the best strength, resistance to corrosion, and cost-effectiveness. It is the most often used version as a result.
The cost of the Hastelloy C276 is reasonable. For a complete price list, get in touch with us. Hastelloy C276 is suitable for a broad range of applications because to its characteristics, which include its density, strength, thermal conductivity, corrosion resistance, and pressure ratings. This article contains a variety of product types. The Hastelloy C276 suppliers use this material to make welding wires, bars, sheets, plates, tubes, and pipes. The substance is resistant to hypochlorite, chlorine dioxide, and wet chlorine gas. Due to its ability to reduce intergranular precipitation during the welding process, it offers corrosion resistance in welded joints.
| Sheets / Plates | Smls Pipes | Welded Pipes | Smls Tube | Welded Tube | Bars / Rods | Forging | Pipe Fitting | |
|---|---|---|---|---|---|---|---|---|
| Hastelloy C-276 | ASTM B564 | B574 | B575 | B619 | B622 | B626 | B366 | B462 |
UNS Designation Number: N10276
W.Nr. Number (DIN): 2.4819
| HASTELLOY® C-276 alloy (N10276, W10276) |
|
| Sheet, Plates & Strips | B 575 / SB 575 P= 43 |
|---|---|
| Billet, Rods & Bars | B 574 / SB 574 P= 43 |
| Coated Electrode | SFA 5.11/ A 5.11 (ENiCrMo-4) DIN 2.4887 (EL-NiMo15Cr15W) F= 43 |
| Bare Welding Rod and Wires | SFA 5.14/ A 5.14 (ERNiCrMo-4) DIN 2.4886 (SG-NiMo16Cr16W) F= 43 |
| Pipes & Tubes - Seamless | B 622 / SB 622 P= 43 |
| Pipes & Tubes -Welded | B 619 /SB 619 P= 43 |
| Pipe Fittings | B 366 / SB 366 P= 43 |
| Forging Products | B 564 / SB 564 P= 43 |
| DIN | 17744 No. 2.4819 NiMo16Cr15W |
| TÜV | Werkstoffblatt 400 Kennblatt 320 Kennblatt 319 |
| Other Stanard | NACE MR0175 ISO 15156 |
Hastelloy C-276 Round Bar:
Hastelloy C-276 round bars are made from a nickel-molybdenum-chromium alloy known for its outstanding corrosion resistance in a wide range of aggressive environments. These bars exhibit high strength and are used in applications such as chemical processing, pollution control, and petrochemical industries.
| Property | Specification |
|---|---|
| Chemical Composition |
|
| Mechanical Properties |
|
| Corrosion Resistance | Excellent resistance to a wide range of corrosive environments, including oxidizing and reducing conditions. |
| Applications | Chemical processing, pollution control, flue gas desulfurization systems. |
Hastelloy C-276 Square Bar:
Hastelloy C-276 square bars are made from a nickel-molybdenum-chromium alloy known for exceptional corrosion resistance in a wide range of aggressive environments. With a chemical composition that includes nickel, chromium, and molybdenum, these square bars exhibit high strength and resistance to pitting, crevice corrosion, and stress corrosion cracking.
| Property | Specification |
|---|---|
| Chemical Composition |
|
| Mechanical Properties |
|
| Corrosion Resistance | Excellent resistance to a wide range of corrosive environments, including oxidizing and reducing conditions. |
| Applications | Chemical processing, pollution control, flue gas desulfurization systems. |
Hastelloy C-276 Hex Bar:
Hastelloy C-276 is a nickel-molybdenum-chromium alloy known for its outstanding corrosion resistance. The hex bars, featuring a chemical composition with a predominant 57% Nickel, exhibit excellent resistance to a wide range of corrosive environments, including oxidizing and reducing conditions. With a minimum tensile strength of 100 ksi, C-276 hex bars find extensive use in chemical processing, pollution control, and flue gas desulfurization systems.
| Property | Specification |
|---|---|
| Chemical Composition |
|
| Mechanical Properties |
|
| Corrosion Resistance | Excellent resistance to a wide range of corrosive environments. |
| Applications | Chemical processing, pollution control, flue gas desulfurization systems. |
Hastelloy C-276 Pipes:
Hastelloy C-276 pipes are made from a nickel-molybdenum-chromium alloy, offering exceptional corrosion resistance. With a chemical composition comprising 57% Nickel, these pipes excel in resisting corrosive environments, including oxidizing and reducing conditions. The pipes demonstrate a high tensile strength, making them suitable for a wide range of applications, such as chemical processing, flue gas desulfurization systems, and pollution control.
| Property | Specification |
|---|---|
| Chemical Composition |
|
| Mechanical Properties |
|
| Corrosion Resistance | Excellent resistance to a wide range of corrosive environments. |
| Applications | Chemical processing, flue gas desulfurization systems, pollution control. |
Hastelloy C-276 sheets and plates are integral components in industrial applications, renowned for their exceptional corrosion resistance and mechanical strength. Composed of nickel, molybdenum, and chromium, this alloy demonstrates remarkable resilience against a diverse array of corrosive substances, making it a preferred choice in aggressive chemical environments. Available in thicknesses ranging from 0.1mm to 100mm, these sheets offer versatility for various fabrication needs. With widths spanning from 10mm to 2500mm and customizable lengths, Hastelloy C-276 sheets cater to a broad spectrum of project requirements. Surface finishes, including 2B, 2D, BA, NO.1, NO.4, NO.8, and more, contribute to both functionality and aesthetics. The alloy is supplied in multiple forms such as coils, foils, rolls, plain sheets, shim sheets, perforated sheets, chequered plates, strips, flats, blanks (circles), and rings (flanges), providing flexibility in application. Cold and hot rolling options accommodate different manufacturing processes. The alloy exhibits varying hardness options, from soft to spring hard, meeting diverse mechanical demands. Notably, Hastelloy C-276 excels in corrosive environments involving sulfuric acid, hydrochloric acid, and chlorine, showcasing superior corrosion resistance. Its high-temperature performance extends its utility to applications involving elevated temperatures. Adhering to standards such as ASTM B575 and ASME SB575, these sheets and plates ensure reliability and quality. With applications spanning chemical processing, pollution control, pulp and paper production, and more, Hastelloy C-276 remains a go-to material. Its ease of fabrication and weldability further enhance its appeal, while ongoing research continues to refine its properties, solidifying its position as a key material in demanding industrial settings.
| Property | Specification |
|---|---|
| Material | Hastelloy C-276 |
| Thickness | 0.1mm to 100mm |
| Width | 10mm to 2500mm |
| Length | 2m, 2.44m, 3m, or as required |
| Surface | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hairline, sand blast, Brush, etching, etc. |
| Finish | Cold rolled, Hot rolled |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard, etc. |
| Standards | ASTM B575, ASME SB575 |
Hastelloy C-276 fasteners represent a critical component in industries demanding high corrosion resistance and exceptional mechanical strength. Comprising nickel, molybdenum, and chromium, this alloy is known for its resistance to a wide range of corrosive environments, including aggressive chemicals and acidic media. Fasteners such as bolts, nuts, screws, and washers made from Hastelloy C-276 exhibit versatility and reliability in various applications. These fasteners are manufactured to precise standards, meeting specifications such as ASTM B574 and ASME SB574, ensuring consistency and quality. Hastelloy C-276 fasteners are available in a variety of sizes and configurations to accommodate diverse industrial requirements. The alloy's resistance to pitting, crevice corrosion, and stress corrosion cracking makes it suitable for challenging environments, including chemical processing, petrochemical, and marine applications. The fasteners are designed to withstand both high temperatures and aggressive chemicals, making them suitable for use in extreme conditions. Hastelloy C-276 fasteners are commonly used in conjunction with other components made from the same alloy to create a corrosion-resistant system. Their durability and reliability contribute to the longevity of structures and equipment in harsh environments. Due to the alloy's excellent workability, Hastelloy C-276 fasteners are easy to install and maintain. The alloy's high melting point and thermal stability further enhance its performance in demanding applications. Ongoing research and development in the field of corrosion-resistant alloys continue to optimize the properties of Hastelloy C-276, ensuring that it remains a top choice for fastening solutions in corrosive and challenging industrial settings.
| Property | Value |
|---|---|
| Material | Hastelloy C-276 |
| Size Range | Customizable |
| Standard | ASTM B574 |
| Grade | UNS N10276 |
| Finish | Plain, Black, Zinc Plated, Hot Dip Galvanized, etc. |
| Thread Type | UNC, UNF, Metric Coarse, Metric Fine, etc. |
| Tensile Strength | Minimum 100 ksi (690 MPa) |
| Yield Strength | Minimum 41 ksi (283 MPa) |
| Eligibility | ISO 9001:2015 |
| Corrosion Resistance | Excellent in corrosive environments |
| Applications | Chemical processing, pollution control, pulp and paper production, etc. |
| Temperature Range | -150°C to 538°C (-238°F to 1000°F) |
| Density | 8.89 g/cm³ |
Hastelloy C-276 Fittings:
Hastelloy C-276 fittings are engineered from a nickel-molybdenum-chromium alloy known for its remarkable corrosion resistance. With a chemical composition comprising 57% Nickel, these fittings exhibit superior resistance to a broad spectrum of corrosive environments. The high tensile strength and malleability make C-276 fittings suitable for applications in chemical processing, oil and gas, and pollution control.
| Property | Specification |
|---|---|
| Chemical Composition |
|
| Mechanical Properties |
|
| Corrosion Resistance | Excellent resistance to a wide range of corrosive environments. |
| Applications | Chemical processing, oil and gas, pollution control. |
Hastelloy C-276 flushing rings play a crucial role in industries requiring robust corrosion resistance and reliability in fluid systems. Composed of nickel, molybdenum, and chromium, Hastelloy C-276 offers exceptional resistance to corrosive media, making it an ideal material for flushing rings. These rings are designed to be inserted into piping systems to flush out impurities, contaminants, or residue, maintaining the integrity and efficiency of fluid handling processes. Manufactured to stringent standards, such as ASTM B574 and ASME SB574, Hastelloy C-276 flushing rings ensure consistent quality and performance. Their corrosion resistance extends to harsh environments, including chemical processing, petrochemical, and offshore applications, where exposure to aggressive substances is common. Flushing rings made from Hastelloy C-276 are available in various sizes and configurations, providing versatility to meet specific system requirements. The alloy's resistance to pitting, crevice corrosion, and stress corrosion cracking enhances the durability of these rings, contributing to the longevity of fluid systems. The high-temperature stability of Hastelloy C-276 is advantageous in applications where elevated temperatures are encountered. The flushing rings' capability to withstand both extreme temperatures and corrosive substances makes them a reliable choice for critical processes.
| Property | Hastelloy C-276 |
|---|---|
| Material | Hastelloy C-276 |
| Composition | Ni 57%, Mo 16%, Cr 15%, Fe 5%, W 4% |
| Corrosion Resistance | Excellent |
| Temperature Resistance | Up to 1,370°C (2,500°F) |
| Strength | High tensile and yield strength |
| Forms | Flushing Rings |
| Applications | Chemical processing, petrochemical, aerospace |
| Dimensional Stability | High |
Hastelloy C-276 thermowells are integral components in industrial temperature measurement systems, offering exceptional corrosion resistance and durability. Comprising nickel, molybdenum, and chromium, Hastelloy C-276 is renowned for its ability to withstand corrosive environments, making it an ideal material for thermowells. These devices are designed to protect temperature sensors such as thermocouples or resistance temperature detectors (RTDs) from the corrosive effects of harsh process fluids. Manufactured to stringent standards like ASTM B574 and ASME SB574, Hastelloy C-276 thermowells ensure consistent and reliable performance in challenging applications. Their corrosion resistance extends to aggressive media encountered in chemical processing, petrochemical, and offshore industries, where accurate temperature monitoring is crucial. Thermowells made from Hastelloy C-276 are available in various configurations to accommodate different temperature sensor designs and installation requirements. The alloy's resistance to pitting, crevice corrosion, and stress corrosion cracking enhances the longevity of these thermowells, ensuring the accuracy of temperature measurements over time. The high-temperature stability of Hastelloy C-276 is advantageous in applications involving elevated temperatures. Hastelloy C-276 thermowells maintain their structural integrity and protect temperature sensors even in demanding operating conditions.
| Property | Hastelloy C-276 |
|---|---|
| Material | Hastelloy C-276 |
| Composition | Ni 57%, Mo 16%, Cr 15%, Fe 5%, W 4% |
| Corrosion Resistance | Excellent |
| Temperature Resistance | Up to 1,370°C (2,500°F) |
| Strength | High tensile and yield strength |
| Forging Process | Enhanced structural integrity |
| Weldability | Good |
| Fabricability | Excellent |
| Applications | Chemical processing, petrochemical, aerospace |
| Dimensional Stability | High |
Hastelloy C-276 forged circles are essential components in industrial applications requiring high corrosion resistance and exceptional strength. Composed of nickel, molybdenum, and chromium, Hastelloy C-276 is renowned for its resilience in aggressive chemical environments, making it an ideal material for forged circles. These circles are crafted through a precision forging process, ensuring uniformity and structural integrity. Manufactured in compliance with stringent standards such as ASTM B564 and ASME SB564, Hastelloy C-276 forged circles guarantee consistency and quality. Their corrosion resistance extends to harsh conditions found in chemical processing, petrochemical, and offshore industries, where exposure to corrosive substances is common. Forged circles made from Hastelloy C-276 are available in various sizes and thicknesses, providing versatility for diverse industrial applications. The alloy's resistance to pitting, crevice corrosion, and stress corrosion cracking enhances the durability of these circles, making them suitable for use in critical components of industrial systems. The high-temperature stability of Hastelloy C-276 is advantageous in applications involving elevated temperatures. Hastelloy C-276 forged circles maintain their structural integrity and mechanical strength even in demanding operating conditions.
| Property | Hastelloy C-276 |
|---|---|
| Material | Hastelloy C-276 |
| Composition | Ni 57%, Mo 16%, Cr 15%, Fe 5%, W 4% |
| Corrosion Resistance | Excellent |
| Temperature Resistance | Up to 1,370°C (2,500°F) |
| Strength | High tensile and yield strength |
| Forging Process | Enhanced structural integrity |
| Weldability | Good |
| Fabricability | Excellent |
| Applications | Chemical processing, petrochemical, aerospace |
| Dimensional Stability | High |
Hastelloy C-276 forged circles are essential components designed to meet the demanding requirements of industries where corrosion resistance and high strength are paramount. Comprised of nickel, molybdenum, and chromium, Hastelloy C-276 is celebrated for its exceptional performance in corrosive environments, making it a preferred choice for forged circles. The forging process ensures the creation of these circles with a high degree of structural integrity and uniformity. Adhering to rigorous standards like ASTM B564 and ASME SB564, Hastelloy C-276 forged circles guarantee a consistent and high-quality product. Their corrosion resistance extends to aggressive chemical settings, making them well-suited for applications in chemical processing, petrochemical, and offshore industries where exposure to corrosive substances is common. Forged circles made from Hastelloy C-276 are available in various sizes and thicknesses, offering versatility for diverse industrial applications. The alloy's resistance to pitting, crevice corrosion, and stress corrosion cracking enhances the longevity and reliability of these circles, positioning them as essential components in critical parts of industrial systems.
| Property | Hastelloy C-276 |
|---|---|
| Material | Hastelloy C-276 |
| Composition | Ni 57%, Mo 16%, Cr 15%, Fe 5%, W 4% |
| Corrosion Resistance | Excellent |
| Temperature Resistance | Up to 1,370°C (2,500°F) |
| Pressure Rating | Dependent on design and application |
| Applications | Flange connections, heat exchangers, pressure vessels |
| Dimensional Stability | High |
| Standards | ASTM, ASME |
